- Waterdrop Undersink Water Filtration System employs an advanced UF membrane, which effectively reduces bacteria, microorganisms, and any contaminants larger than 0.01μm.[1]
- The advanced four-stage filtration also effectively reduces chlorine, taste and odor, sediment, rust, and other heavy metals, which is tested by the third-party laboratory.
- Premium lead-free materials are fully certified by the WQA against NSF 372 standard. BPA-free materials are also ensured. Effective chlorine reduction is certified against NSF 42 standard by the WQA.
- With innovative push-to-connect fittings, the entire installation process takes less than 3 minutes. The twist-and-lock design ensures that you can replace the filter in 3 seconds without any tools.
- The extended filter life ensures the filtration capacity of 8,000, 16,000, 24,000 gallons, this under sink water filter system delivers safe filtered water all day long.[2]
Under Sink Ultrafiltration Water Filter | Direct Connect Filtration System
Sign up for restock notifications
Under Sink Ultrafiltration Water Filter | Direct Connect Filtration System
Model number
WD-10UA-UF
WD-15UA-UF
WD-17UA-UF
Compatibility
Suitable for faucets with 1/2" or 3/8" FEMALE NPT thread. If a female threaded connector is needed to connect to your faucet, please contact us BEFORE purchase.
Product dimensions
WD-10UA-UF: 3.6" * 3.85" * 12.3"
WD-15UA-UF: 3.6" * 3.85" * 16.7"
WD-17UA-UF: 3.6" * 3.85" * 19.1"
Operating temperature
2-38℃/35-100℉
Materials
System cover: BPA-free plastic
Faucet: metal
Filter: Polyester membrane Ultrafiltration (UF) membrane Activated carbon block KDF
Item weight
WD-10UA-UF: 3.30 lb
WD-15UA-UF: 3.63 lb
WD-17UA-UF: 4.20 lb
Color
Black
Included components
Waterdrop Undersink Water Filtration System ×1
Inlet hose ×1
Outlet hose ×1
3/8"- 1/2" Convertor set ×1
Self-tapping screws ×1
Teflon tape ×1 and Drilling sticker ×1

UF membrane
- Bacteria, microorganisms, and any contaminants larger than 0.01μm cannot go through the ultrafiltration membrane, which results in excellent filtration performance.[1]
but efficient design
- The compact design saves a significant amount of under-sink space and creates more room for storage.


installation
- Easy installation takes only
3minutes.
- Replacing the filter also takes only
3seconds.
- The push-to-connect fittings make installation easier, saving you time and effort.
- This under counter water filtration system has a stable water flow and high filtration efficiency. The tested full flow rate is 0.75 gpm at 60 psi. You’ll get filtered water without the wait.
- Waterdrop Undersink Water Filtration System has different options for connecting to your original faucet, a dedicated Waterdrop faucet, or your refrigerator. Click here to connect with the dedicated faucet.




- Four-stage filtration. This under-sink water purification system adopts an advanced ultrafiltration membrane to reduce bacteria, chlorine, odor, sediment, rust,and other heavy metals, which is tested by the third-party laboratory.. You don’t have to worry about the safety of the filtered water.[1]
- The under counter water filter system also retains minerals that are essential to your body, such as potassium, calcium, sodium, and magnesium. Enjoy fresh, healthy water with Waterdrop.
- Filtration capacity:
- 8,000 gallons
- 16,000 gallons
- 24,000 gallons
- Waterdrop Undersink Water Filtration System can meet a tap water consumption of 22 gallons a day.[2]


- On average, you’ll spend 10¢ per day for the first year. You’ll pay only 5¢ per day for the filter replacement and your water quality will improve with each passing day.
- Note: Cost varies according to product model.
![]() UA-UF Ultra-Filtration System |
![]() UB-UF Ultra-Filtration System |
![]() UC-UF Ultra-Filtration System |
![]() TSU Ultrafiltration System |
![]() TSC Filtration System |
|
Situation | Undersink/RV/Bathroom | Undersink/RV/Bathroom | Refrigerator/Icemaker/RV | Undersink | Undersink |
---|---|---|---|---|---|
Micron Rating | 0.01μm | 0.01μm | 0.01μm | 0.01μm | 0.5 μm |
Upgrade Filter Material | Adding 0.01 micron ultrafiltration membrane | Adding 0.01 micron ultrafiltration membrane | Adding 0.01 micron ultrafiltration membrane | Adding 0.01 micron ultrafiltration membrane | × |
Removable Substances | Contaminants larger than 0.01 μm, Chlorine, Taste and Odor, Sediment, Rust, Heavy Metals | Contaminants larger than 0.01 μm, Chlorine, Taste and Odor, Sediment, Rust, Heavy Metals | Contaminants larger than 0.01 μm, Chlorine, Taste and Odor, Sediment, Rust, Heavy Metals | Most of contaminants larger than 0.01 micron | Most of chlorine, lead, mercury, fluoride, arsenic, taste and odor |
Filtration Capacity | 8000/16000/24000 Gallons | 8000/16000/24000 Gallons | 8000/16000/24000 Gallons | 6/12/24 Months | 6/12/24 Months |
Gallons Per Minute | 2 GPM | 2 GPM | 2 GPM | 0.6 GPM | 0.6 GPM |
Reduce TDS | No | No | No | No | No |
Retain Beneficial minerals | √ | √ | √ | √ | √ |
Dedicated Faucet | × | v | × | √ | √ |
Can I use this system with well water?
Can this system reduce TDS?
Can this system inhibit bacteria?
What is the filter service life?
Where can I buy a replacement filter?
Can this system replace my refrigerator filter?
What is the water pressure?
